1	Performance Tuning Web Applications Dr. Paul Dorsey & Michael Rosenblum Dulcian, Inc. www.dulcian.com June 23, 2009
2	Why Performance Tuning Fails We are solving the wrong problem. Tuning: Usually makes the database run better. Focuses on poorly running SQL. Web applications are frequently unaffected by these performance improvement approaches. Need to examine the entire system, not just the database.
3	Web Application Architecture
4	Steps 1 & 9 - Client
5	Step 2 - Client to Application Server Less common cause of performance problems Transmitting large amounts of information over the Internet may cause problems. Uploading large files Transmitting a large block of data
6	Steps 3 & 7 Application Server Processing Performance Problems Processing can be resource-intensive. Java programmers minimize database application logic in the middle tier. Complex data manipulation can be handled much more efficiently with database code. Thick database approach is the key to efficiently performing web applications.
7	Step 4 - Application Server to Database Not instantaneous (but really fast) High number of transmission requests are the #1 cause of performance problems. Database-independence is not a good idea. Single request from a client may require many requests from the application server to the database in order to fulfill. Examine and measure the number of round-trips from application server to database.
8	Step 5 - Database Performance Problems Use traditional tuning. Beware of stateless implementation. Information pertaining to a particular session must be retrieved at the beginning of every request and persistently stored at the end of every request. Single table may generate massive I/O Redo logs Block contention
9	Step 6 - Database to Application Server Transmission Problems Rare problem Beware of unnecessary data movement. One record is needed and the whole table is sent.
10	Step 8 - Application Server to Client Transmission Problems #2 cause of performance problems Keep pages small. Not too many fields Not too much AJAX or JavaScript Not too big a tree Not too much data in a scrolling block No images, or other unnecessary information Measure size of page.
11	Locating Slow Performance Causes Embed timers into a system to detect where in the nine possible steps the application performance is degrading. Strategically placed timers will indicate how much time is spent at any one of the steps in the total process.
12	Common Causes of Performance Problems The most common causes of slow system performance are: 1. Excessive round-trips from the application server to the database 2. Large pages sent to the client 3. Performing operations in the application server that should be done in the database 4. Poorly written SQL and PL/SQL routines
13	"Measuring Performance" Measuring Performance
14	Timing Language Elements Command: Atomic part of the process (any command on any tier) Step: Complete processing cycle in one direction (always one-way) Can either be a communication step between one tier and another, or a set of steps within the same tier. Step consists of a number of commands. Request: Action consisting of a number of steps. A request is passed between different processing tiers. Round-trip: Complete cycle from the moment the request leaves the tier to the point when it comes back with some response information.
15	System Tuning for 3-tier Application (with numbers!)
16	Actions in 5 Round-Trip Structure Client Level 1. From request initiation to end of processing User clicks button Response is displayed 2. From request to application server to response receipt Start of servlet call End of servlet call
17	Review Still to discuss SQL tuning Application server / database communication tuning Managing persistent layer Topics Covered Steps in web application process Places where performance can suffer Measuring performance
18	SQL Tuning: REMEMBER!!! 1. Use bind variables. 2. Use bind variables. 3. Use bind variables. 4. Use bind variables. 5. Use bind variables. 6. Use bind variables. 7. Use bind variables. © Tom Kyte
19	Simple Case The problem: Value lists are explicitly hard-coded across the system Difficult to determine what exactly is used Hard to maintain Data-dependent (cannot be cached) The solution – single tuning point! Universal Value List Builder
20	Universal Value List (1) Specify exactly what is needed as output and declare the corresponding collection: Create type lov_oty is object (id_nr NUMBER, display_tx VARCHAR2(256)); Create type lov_nt as table of lov_oty;
21	Universal Value List (2) Write a PL/SQL function to hide all required logic: function f_getLov_nt (i_table_tx,i_id_tx,i_display_tx,i_order_tx) return lov_nt is v_out_nt lov_nt := lov_nt(); begin execute immediate 'select lov_oty(' \|\|i_id_tx\|\|','\|\|i_display_tx\|\| ')'\|\| ' from '\|\|i_table_tx\|\| ' order by '\|\|i_order_tx bulk collect into v_out_nt; return v_out_nt; end;
22	Universal Value List (3) Test SQL statement with the following code: select id_nr, display_tx from table( cast(f_getLov_nt (:1, -- 'emp' :2, -- 'empno' :3, --'ename\|\|''-''\|\|job' :4 -- 'ename‘ ) as lov_nt) )
23	Complex Case The problem: Users upload CSV-files Name of file defines type Column headers map directly to table columns. One row of file could mean multiple inserts Wrong solution Parse file in the middle-tier and build inserts. Right solution: Load file to the database as CLOB. Build all inserts in the database.
24	Build Inserts Declare type integer_tt is table of integer; v_cur_tt integer_tt; Begin for r in v_groupRow_tt.first..v_groupRow_tt.last loop v_cur_tt(r):=DBMS_SQL.OPEN_CURSOR; for c in c_cols(v_mapRows_tt(r)) loop for i in v_header_tt.first..v_header_tt.last loop if v_header_tt(i).text=c.name_tx then v_col_tt(i):=c; v_col_tx:=v_col_tx\|\|','\|\|v_col_tt(i).viewcol_tx; v_val_tx:=v_val_tx\|\|',:'\|\|v_col_tt(i).viewcol_tx; end if; end loop; end loop; v_sql_tx:='insert into '\|\|v_map_rec.view_tx\|\| '('\|\|v_col_tx\|\|') values('\|\|v_value_tx\|\|')'; DBMS_SQL.PARSE(v_cur_tt(r),v_sql_tx,DBMS_SQL.NATIVE); end loop;
25	Process Data for i in 2..v_row_tt.count loop for r in v_groupRow_tt.first..v_groupRow_tt.last loop for c in v_col_tt.first..v_col_tt.last loop if v_col_tt(c).id = v_mapRows_tt(r) then DBMS_SQL.BIND_VARIABLE(v_cur_tt(r), ':'\|\|v_col_tt(c).viewcol_tx, v_data_tt(c).text); end if; end loop; v_nr:=dbms_sql.execute(v_cur_tt(r)); end loop; end loop;
26	Application Server / Database Critical success factor – managing database sessions: Almost impossible to have one session per connection Cost of opening/closing sessions is high. Opportunity: Total number of physical sessions at any point in time is fairly small. Good idea: Create connection pool with a fixed number of connections (using Autoextend option). Serve them to incoming requests as needed. Problems: A single physical session can serve requests from different logical sessions at different points in time. Cannot trust ANYTHING defined at the session level.
27	Connection Pooling (1) Packaged variables cleanup begin dbms_session.reset_package; dbms_session.free_unused_user_memory; end;
28	Connection Pooling (2) Temporary tables cleanup procedure p_truncate is v_exist_yn varchar2(1); Begin select 'Y' into v_exist_yn from v$session s, v$tempseg_usage u where s.audsid = SYS_CONTEXT('USERENV','SESSIONID') and s.saddr = u.session_addr and u.segtype = 'DATA' and rownum = 1; for c in (select table_name from user_table where temporary = 'Y‘ and duration = 'SYS$SESSION') loop execute immediate 'truncate table '\|\|c.table_name; end loop; end;
29	Managing Persistent Layer Web - idea Create persistent table Add session ID Estimate system could slow down 3-5% Web - real life 50%-200% slower (only at peak times) Workload limit after which the whole system started to fall apart Client/Server Temporary table with supporting information (one row per session) Read - from support area. Write – via the engine: Get action from the application Modify support area Send response to the application Reason Eliminates about 75% of repeated requests
30	Why is performance affected? (1) Database running in ARCHIVELOG All DML against SUPPORT table recorded Filled up about 85% of all logs! All support changes must be persistent. Extra COMMITS occurred LOG FILE SYNC wait event count skyrocketed Table had primary key (ID from a sequence) Due to DML activity from hundreds of sessions, every 15 minutes, the database logged a deadlock. Very high contention on some index blocks
31	"Cumulative heavy I/O load" Cumulative heavy I/O load Individual requests take more time. Sessions were not released from connection pool fast enough. Total number of simultaneous sessions is 4 times more than estimated. Each session used more memory, more temporary segments, etc. Slowed down the system even more Especially true for I/O operations (since there were more simultaneous requests). Quickly spirals into a slow-down and eventual stoppage of the system
32	"Database resources quickly became over-utilized..." Database resources quickly became over-utilized just by making a table persistent with a session key. Two core issues: 1. How to decrease I/O? 2. How to resolve index contention?
33	Solution Create a separate database instance New instance runs in NOARCHIVELOG mode New instance has only one schema. That schema contains only one table: SUPPORT INFO SUPPORT INFO table is hash-partitioned by session ID (1024 partitions) All indexes are local. Main schema has a database link and synonym Everything appears as though nothing has changed. All requests to the support table must include session ID (to use local indexes). Some rewrite was required to enforce this rule.
34	Result System ran as fast as originally predicted. Extra waits caused by data cases via DBLink were negligible (less than 0.01/request - average of 3000 requests/hour). No time lost writing logs Less I/O à less sessions à less resources used à less waits à faster response à less sessions … Using a large number of partitions, less chances of creating a “hot block”, since all indexes were local. Lessons learned: In the Oracle environment, everything is linked together. Any changes can lead to a “domino effect.”
35	Conclusions Keep all nine of the potential areas for encountering performance problems in mind. Investigate each one carefully to discover ways in which performance can be improved. It is not just the database.
